Tech Specs
RATED LINE PULL 11,000LB (4,990KG)
MOTOR (12V) 5.0KW/6.7HP; (24V) 6.0KW/8.2HP
GEAR TRAIN FULL STEEL 3 STAGE PLANETARY
GEAR RATIO 228:1
CLUTCH TYPE STAINLESS STEEL ROTARY CLUTCH
CLUTCH HANDLE POSITION GEARBOX CAN BE ROTATED
BRAKE AUTOMATIC RATCHET LOAD HOLDING IN GEARBOX
CABLE TYPE NOT INCLUDED. YOU CAN USE STEEL CABLE OR SYNTHETIC ROPE
CABLE SIZE NOT INCLUDED WITH BARE WINCH. MAX DRUM CAPACITY ? 30M X 10MM
DRUM SIZE 63MM X 217MM
MOUNTING BOLT PATTERN 254MM X 114.3MM
OVERALL DIMENSIONS 574MM X 160MM X 200MM
REMOTE CONTROL NOT INCLUDED WITH BARE WINCH
BATTERY LEADS NOT INCLUDED WITH BARE WINCH
FINISH BLACK POWDER COAT
WARRANTY LIMITED 5 YEAR ELECTRICAL AND LIFETIME MECHANICAL WARRANTY
SHIPPING WEIGHT 25.00KG
SHIPPING WIDTH 0.330M
SHIPPING HEIGHT 0.330M
SHIPPING LENGTH 0.640M
