Tech Specs | RATED LINE PULL 25,000LB (11,340KG) | MOTOR (12V) 5.5KW/7.4HP; (24V) 6.1KW/8.2HP | GEAR TRAIN FULL STEEL 3 STAGE PLANETARY | GEAR RATIO 450:1 | CLUTCH TYPE STAINLESS STEEL ROTARY CLUTCH | CLUTCH HANDLE POSITION GEARBOX CAN BE ROTATED | BRAKE AUTOMATIC RATCHET LOAD HOLDING IN GEARBOX | CABLE TYPE AIRCRAFT GRADE STEEL CABLE | CABLE SIZE 13.8MM X 26.5M | DRUM SIZE 120MM X 198MM | MOUNTING BOLT PATTERN 254MM X 114.3MM; 254MM X 190.5MM (8X M12 BOLTS) | OVERALL DIMENSIONS 638MM X 298MM X 300MM | REMOTE CONTROL HEAVY DUTY HANDHELD + WIRELESS | BATTERY LEADS 2X 1.8M HEAVY DUTY LEADS | FINISH MATT BLACK POWDER COAT | WARRANTY LIMITED 5 YEAR ELECTRICAL AND LIFETIME MECHANICAL WARRANTY (18 MONTH COMMERCIAL USE WARRANTY) | SHIPPING WEIGHT 120.00KG | SHIPPING WIDTH 0.410M | SHIPPING HEIGHT 0.450M | SHIPPING LENGTH 0.740M
Technical Specifications & Fitment
