Tech Specs
RATED LINE PULL 12,000LB (5,443KG)
MOTOR (12V) 4.0KW/5.4HP; (24V) 6.5KW/8.7HP
GEAR TRAIN FULL STEEL 3 STAGE PLANETARY
GEAR RATIO 253:1
CLUTCH TYPE SLIDING RING GEAR
CLUTCH HANDLE POSITION GEARBOX CAN BE ROTATED
BRAKE AUTOMAUTOMATIC RATCHET LOAD HOLDING IN THE GEARBOX
CABLE TYPE AIRCRAFT GRADE STEEL CABLE
CABLE SIZE STEEL CABLE: 11MM X 25M
DRUM SIZE 63MM X 223MM
MOUNTING BOLT PATTERN 254MM X 114.3MM
OVERALL DIMENSIONS 553MM X 160MM X 200MM
REMOTE CONTROL HEAVY DUTY HANDHELD + WIRELESS
BATTERY LEADS 2X 1.8M HEAVY DUTY LEADS
FINISH BLACK POWDER COAT
WARRANTY LIMITED 5 YEAR ELECTRICAL AND LIFETIME MECHANICAL WARRANTY
SHIPPING WEIGHT 42.00KG
SHIPPING WIDTH 0.630M
SHIPPING HEIGHT 0.330M
SHIPPING LENGTH 0.330M
