Carbon Offroad 6000lb ATV/Small 4X4 Winch

Technical Features
Part number: CW-XD6
Rated line pull: 6000 lbs, (2725kg) single-line
Motor: 12V DC 2.5 HP permanent magnet (Available in 24V)
Remote Control: Handlebar Mini-Rocker
Wireless Remote Control: Included
Geartrain: 3-Stage Planetary
Gear Ratio: 147:1
Clutch: Roller disc full load automatic
Brake: Automatic brake in the motor bracket
Aluminium hawse
Lifetime Mechanical Warranty
5 Year Electrical Warranty
IP Rating: IP66 for winch and solenoid (excludes remote control and switch)
Synthetic Rope: 16m x 6.5mm diameter
Drum Diameter/Length: 51mm x 122mm
Mounting Bolt Pattern: 167mm x 76mm
Recommended Battery: 650 CCA minimum for winching
Winch Dimensions (L x W x H): 385 x 115 x 119mm
Packing Dimensions (L x W x H): 530 x 170 x 230mm
Winch weight with synthetic rope attached: 8.3kg
Winch weight including synthetic rope, control box complete with cables, mounting bolts & fairlead: 11.2kg

Supplier / Brand	Carbon Offroad
SKU	CW-XD6
Category / Fitment	Winches & Winch Accessories
Shipping & Fitting	Professional fitting available at our Warana (Sunshine Coast) & Gympie workshops or nationwide delivery.
