• Carbon Offroad Long Drum 6000lb ATV/Small 4X4 Winch
1 1

Carbon Offroad

Suspension & Recovery

Carbon Offroad Long Drum 6000lb ATV/Small 4X4 Winch

ENQUIRY ONLY
Taxes included.
Technical FeaturesPart number: CW-XD6LRated line pull: 6000 lbs, (2725kg) single-lineMotor: 12V DC 2.5 HP permanent magnetRemote Control: Handlebar Mini-RockerWireless Remote Control: IncludedGeartrain: 3-Stage PlanetaryGear Ratio: 147:1Clutch: Roller disc full load automaticBrake: Automatic... SHOW MORE ↓
View full details
Technical Features
Part number: CW-XD6L
Rated line pull: 6000 lbs, (2725kg) single-line
Motor: 12V DC 2.5 HP permanent magnet
Remote Control: Handlebar Mini-Rocker
Wireless Remote Control: Included
Geartrain: 3-Stage Planetary
Gear Ratio: 147:1
Clutch: Roller disc full load automatic
Brake: Automatic brake in the motor bracket
Aluminium hawse
Lifetime Mechanical Warranty
5 Year Electrical Warranty
IP Rating: IP66 for winch and solenoid (excludes remote control and switch)
Synthetic Rope: 26m x 6.5mm diameter
Drum Diameter/Length: 51mm x 208mm
Mounting Bolt Pattern: 254mm x 76mm
Recommended Battery: 650 CCA minimum for winching
Winch Dimensions (L x W x H): 473 x 125 x 120mm
Packing Dimensions (L x W x H): 530 x 170 x 230mm
Winch weight with synthetic rope attached: 8.3kg
Winch weight including synthetic rope, control box complete with cables, mounting bolts & fairlead: 11.2kg

Technical Specifications & Fitment

Supplier Carbon Offroad
