• Carbon Scout Pro - 10000lb Winch V3
1 1

Carbon Offroad

Suspension & Recovery

Carbon Scout Pro - 10000lb Winch V3

ENQUIRY ONLY
Taxes included.
Technical FeaturesPart number: CW-XD10Rated line pull: 10000 lbs, (4536kg) single-lineMotor: 12V DC 6 HP series wound motor (24V option available)Remote Control: Wired with 3.7m leadWireless Remote Control: IncludedGeartrain: 3-Stage PlanetaryGear Ratio: 180:1Rotating... SHOW MORE ↓
View full details
Technical Features
Part number: CW-XD10
Rated line pull: 10000 lbs, (4536kg) single-line
Motor: 12V DC 6 HP series wound motor (24V option available)
Remote Control: Wired with 3.7m lead
Wireless Remote Control: Included
Geartrain: 3-Stage Planetary
Gear Ratio: 180:1
Rotating Ring Gear
Brake: Automatic brake in the motor bracket
Fairlead: Carbon Offroad MEGAPRO Premium CNC billet type 3 hard anodised multi position fairlead
Lifetime Mechanical Warranty
5 Year Electrical Warranty
5 Year Water Ingress Protection Warranty
Synthetic Rope: 24m x 10mm diameter
Drum Diameter/Length: 63mm x 224mm
Mounting Bolt Pattern: 254mm x 114.3mm
Recommended Battery: 650 CCA minimum for winching
Winch Dimensions (L x W x H): 538 x 158 x 187mm (21.2" x 6.2" x 7.4")
Packing Dimensions (L x W x H): 580 x 200 x 220mm
Winch weight with synthetic rope attached: 19.0kg
Winch weight including synthetic rope, control box complete with cables, mounting bolts & fairlead: 26.7kg

Technical Specifications & Fitment

Colour Purple
Supplier Carbon Offroad
