Carbon Scout Pro - 15000lb Winch V3

ENQUIRY ONLY
Taxes included.
Technical FeaturesPart number: CW-XD15-V3Rated line pull: 15000 lbs, (6803kg) single-lineMotor: 12V DC 7 HP series wound motor (24V option available)Remote Control: Wired with 3.6m leadWireless Remote Control: IncludedGeartrain: 3-Stage PlanetaryGear Ratio: 218:1Rotating... SHOW MORE ↓
View full details
Technical Features
Part number: CW-XD15-V3
Rated line pull: 15000 lbs, (6803kg) single-line
Motor: 12V DC 7 HP series wound motor (24V option available)
Remote Control: Wired with 3.6m lead
Wireless Remote Control: Included
Geartrain: 3-Stage Planetary
Gear Ratio: 218:1
Rotating Ring Gear
Brake: Automatic brake in the motor bracket
Fairlead: Carbon Offroad MEGAPRO Premium CNC billet type 3 hard anodised multi position fairlead
Lifetime Mechanical Warranty
5 Year Electrical Warranty
5 Year Water Ingress Protection Warranty
Synthetic Rope: 24m x 11mm diameter
Drum Diameter/Length: 63.5mm x 224mm
Mounting Bolt Pattern: 254mm x 114.3mm
Recommended Battery: 650 CCA minimum for winching
Winch Dimensions (L x W x H): 556.5 x 158 x 187mm
Packing Dimensions (L x W x H): 580 x 200 x 220mm
Winch weight including synthetic rope, control box complete with cables, mounting bolts & fairlead: 26.7

Technical Specifications & Fitment

Colour Purple
Supplier Carbon Offroad
