• Carbon Scout Pro - 20000lb Extreme Duty Truck Winch
1 1

Carbon Offroad

Suspension & Recovery

Carbon Scout Pro - 20000lb Extreme Duty Truck Winch

ENQUIRY ONLY
Taxes included.
Technical FeaturesPart number: CW-XD20Rated line pull: 20000 lbs, (9072kg) single-lineMotor: 12V DC 7 HP series wound motor (24V option available)Remote Control: Wired with 3.6m leadWireless Remote Control: IncludedGeartrain: 3-Stage PlanetaryGear Ratio: 345:1Rotating... SHOW MORE ↓
View full details
Technical Features
Part number: CW-XD20
Rated line pull: 20000 lbs, (9072kg) single-line
Motor: 12V DC 7 HP series wound motor (24V option available)
Remote Control: Wired with 3.6m lead
Wireless Remote Control: Included
Geartrain: 3-Stage Planetary
Gear Ratio: 345:1
Rotating Ring Gear
Brake: Automatic brake in the motor bracket
Fairlead: Carbon Offroad MEGAPRO Premium CNC billet type 3 hard anodised multi position fairlead
Lifetime Mechanical Warranty
5 Year Electrical Warranty
5 Year Water Ingress Protection Warranty
Synthetic Rope: 25m x 13mm diameter
Drum Diameter/Length: 88mm x 224mm
Mounting Bolt Pattern: 254mm x 114.3mm
Recommended Battery: 650 CCA minimum for winching
Winch Dimensions (L x W x H): 579 x 192 x 224mm
Packing Dimensions (L x W x H): 640 x 250 x 345mm
Winch weight with synthetic rope attached: 30kg
Winch weight including synthetic rope, control box complete with cables, mounting bolts & fairlead: 37kg

Technical Specifications & Fitment

Colour Purple
Supplier Carbon Offroad
